ASUS ProArt -RTX5070TI-O16G NVIDIA GeForce RTX 5070 Ti 16 GB GDDR7
ASUS ProArt -RTX5070TI-O16G NVIDIA GeForce RTX 5070 Ti 16 GB GDDR7
Key Features
- Graphics Processor:
- Interface Type:
- Memory Type:
- Memory Bus:
- Maximum Resolution:
- Ports:
Overview
Visionary. Versatile. Timeless.
The ProArt GeForce RTX™ 5070 Ti combines a compact 2.5-slot design with potent cooling – three Axial-tech fans, a vapor chamber, and a phase-change GPU thermal pad – to deliver GeForce RTX 50 Series performance to both full-scale towers and space-saving SFF builds. A USB Type-C� port enhances versatility for content creation workflows, while a wood-patterned laminate trim and low-key Aura-lit logo help deliver a refined aesthetic.
| Processor | |
|---|---|
| Graphics processor family | NVIDIA |
| Processor boost clock speed | 2588 MHz |
| Parallel processing technology support | Not supported |
| Maximum displays per videocard | 4 |
| CUDA cores | 8960 |
| CUDA | Yes |
| Maximum resolution | 7680 x 4320 pixels |
| Graphics processor | GeForce RTX 5070 Ti |
| Processor frequency (OC mode) | 2610 MHz |
| Memory | |
| Discrete graphics card memory | 16 GB |
| Data transfer rate | 28 Gbit/s |
| Memory bus | 256 bit |
| Graphics card memory type | GDDR7 |
| Ports & interfaces | |
| HDMI version | 2.1b |
| Mini HDMI ports quantity | 0 |
| Mini DisplayPorts quantity | 0 |
| HDMI ports quantity | 1 |
| DisplayPort version | 2.1b |
| DVI-I ports quantity | 0 |
| DVI-D ports quantity | 0 |
| DisplayPorts quantity | 2 |
| Interface type | PCI Express 5.0 |
| USB Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| Video | |
| OpenGL version | 4.6 |
| HDMI version | 2.1b |
| HDCP | Yes |
| Dual Link DVI | No |
| CUDA cores | 8960 |
| Performance | |
| NVIDIA G-SYNC | Yes |
| OpenGL version | 4.6 |
| HDCP | Yes |
| Dual Link DVI | No |
| HDCP version | 2.3 |
| Overclocked (OC) edition | Yes |
| Design | |
| Number of fans | 3 fan(s) |
| Cooling type | Active |
| Product colour | Multicolour |
| Number of slots | 2.5 |
| Cooling technology | ASUS Axial-tech |
| SFF ready | Yes |
| Software | |
| Windows operating systems supported | Yes |
| Power | |
| Supplementary power connectors | 1x 16-pin |
| Minimum system power supply | 850 W |
| Weight & dimensions | |
| Number of slots | 2.5 |
| Weight | 1.39 kg |
| Height | 126 mm |
| Depth | 50 mm |
| Length | 304 mm |
| Technical details | |
| Cooling type | Active |
| Product colour | Multicolour |
| System requirements | |
| Windows operating systems supported | Yes |
| Minimum system power supply | 850 W |
| Packaging data | |
| Package type | Box |
| Package width | 405 mm |
| Package height | 88.5 mm |
| Package depth | 233 mm |
| Package weight | 2.04 kg |
